All In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid System

Product Categories
guangzhou pmd technology co ltd
Contact Now

All In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid System

Place of Origin : china

MOQ : negotiated

Price : negotiated

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : negotiated

Warranty : 15 Years

Weight : 48Kg

Rated Voltage : 102.4V

Rated Energy : 5.12kwh

Rated Capacity : 50Ah

Battery Size : 646mm*330mm*188mm

Contact Now

All-In-One Off Grid 5Kva Solar Storage System 5.12KWH 102.4V Hybrid Solar Energy Panel System Complete For Home

Product details

Rated Energy(kwh) 5.12
Usoblo Energy(kwh) 488
configuration ip32s
Rated Voltage(v) 102.4
Voltage Rongo(VDC) 91.2-115.2
Rated Capacity(Ah) 50
Max Charge/Discharge current (A) 5/8
Communication CAN/RS485
Scalability up to 8s
Humidity ≤95%
Operating Temperature (℃) charge:-10°C-50°C; Discharge -20°C-50°C
Dimension(w/d/h)(mm) 648*330*188
Weight(kg) ≤48
installation Mode Stock
ingress Protection IP65
Altitude (m) ＜2000
Safety UN38.3/IEC61000/IEC62619/CE
Cycle Life 6000 cyclo @25°C,95%DOD,60%EOL
Design Life 15years(25°C)
All In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid System
All In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid System
All In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid System
All In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid SystemAll In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid System
All In One Off Grid Energy Storage 5Kva 5.12KWH 102.4V Solar Panel Hybrid System
Q1. What’s the life of Lead Acid Battery Replaced By Lithium Battery ?
A: 100% DOD Cycles, 1C/1C>2000times; 80% DOD Cycles, 1C/C>5000 times.

Q2: Can the battery be connect in parallel?
A: Yes, it supports in parallel.

Q3: Can the Lithium Battery work with my hybrid inverter?
A: Yes, the Lead Acid Battery Replaced By Lithium Battery suitable for all off grid and hybrid inverter.

Q4: What’s the warranty of Lead Acid Battery Replaced By Lithium Battery?
A: 5 -10 years, we support extended warranty services.

Q5: What is the battery output power?
A: 2.56 KW.

Q6: Does the Lead Acid Battery Replaced By Lithium Battery including inverter?
A: No, battery only, so it is more flexible to work with different brand of inverter preferred by customer.

Q7: Does the Lead Acid Battery Replaced By Lithium Battery with communication function?
A: NO. But it has bluebooth (Bluetooth with Mobile APP), it is optional.
Q8: What is the Waterproof Rate?
A: It is IP65.
